2026 Trailblazer Specs and Sizing Hot Springs AR
Specs and Sizing
2026 Trailblazer Specs and Sizing Hot Springs AR
Engine, MPG, cargo, interior dimensions and safety ratings for the 2026 Trailblazer, each sourced.
The 2026 Chevrolet Trailblazer runs a 137-hp 1.2L turbo or an optional 155-hp 1.3L turbo, spans 174.1 inches long, and holds 25.3 cubic feet of cargo behind the rear seats (54.4 with them folded). Every figure below is sourced and current as of this build, for Hot Springs, Malvern and Arkadelphia shoppers comparing it against anything else in this class. See the Overview for pricing and trim positioning, or the Trims and Pricing page for the full lineup breakdown.
Key Numbers
- 174.1 in. long, 71.2 in. wide (excl. mirrors), 65.2 in. tall, on a 104.0 in. wheelbase.
- 25.3 cu. ft. of cargo behind the rear seats, 54.4 cu. ft. maximum, 123.5 cu. ft. total passenger volume.
- 30 mpg combined on the base 1.2L FWD; up to 31 combined on the 1.3L FWD.
- NHTSA: 5 stars frontal, 4 stars rollover. IIHS: Good on small overlap front and side tests.
- Warranty: 3 yr/36,000 mi bumper-to-bumper, 5 yr/60,000 mi powertrain, 6 yr/100,000 mi rust-through.
Engine Specifications
| Engine | Horsepower | Torque | Transmission |
|---|---|---|---|
| 1.2L Turbo I-3 (standard) | 137 hp @ 5,000 rpm | 162 lb-ft @ 2,500 rpm | CVT |
| 1.3L Turbo I-3 (available/std on RS, ACTIV) | 155 hp | 174 lb-ft | CVT (FWD) or 9-spd automatic (AWD) |
The 1.2L is E85 flex-fuel capable and standard on LS and LT. The 1.3L is standard on RS and ACTIV, a $395 option on LS and LT, and the only engine paired with all-wheel drive.
Exterior Dimensions
| Dimension | Value |
|---|---|
| Length | 174.1 in. |
| Width (excl. mirrors) | 71.2 in. |
| Height | 65.2 in. |
| Wheelbase | 104.0 in. |
| Curb weight (1.2L FWD) | 3,029 pounds |
Interior Dimensions and Cargo Space for Hot Springs Families
| Measure | Front | Rear |
|---|---|---|
| Head room | 40.0 in. | 38.4 in. |
| Leg room | 40.9 in. | 39.0 in. |
| Shoulder room | 55.4 in. | 53.8 in. |
| Hip room | 52.3 in. | 50.4 in. |
| Cargo Measure | Value |
|---|---|
| Behind rear seats | 25.3 cu. ft. |
| Maximum, seats folded | 54.4 cu. ft. |
| Total passenger volume | 123.5 cu. ft. |
| Maximum cargo length (fold-flat front seat) | 8.5 ft. |
| Seating | 5 |
Every Trailblazer seats five on cloth upholstery, with a fold-flat front passenger seat standard from LS on up. That's enough for a full-size stroller behind the rear seats with room beside it, or two large suitcases and two carry-ons for a family trip.
Capacity and Capability
Rated to tow up to 1,000 pounds, properly equipped with the available trailering package, on front- or all-wheel drive. That's a light single-axle utility trailer, not a boat or a travel trailer.
Wheels, Tires and Colors
LS rides on 17-inch silver-painted aluminum wheels; LT and ACTIV move to 17-inch high-gloss-black machined-aluminum wheels; RS steps up to 19-inch high-gloss-black machined-aluminum wheels. An 18-inch wheel option is available for $495. The lineup offers seven exterior colors and two interior color combinations, both cloth.
Fuel Economy and Range
| Config | City | Highway | Combined |
|---|---|---|---|
| 1.2L Turbo FWD | 30 MPG | 31 MPG | 30 MPG |
| 1.3L Turbo FWD | 29 MPG | 33 MPG | 31 MPG |
| 1.3L Turbo AWD | 26 MPG | 29 MPG | 27 MPG |
EPA figures via fueleconomy.gov. Fuel tank: 13.2 gallons on all configurations.
Key Features by Trim
| Feature | LS | LT | RS | ACTIV |
|---|---|---|---|---|
| 11-in touchscreen | standard | standard | standard | standard |
| Wireless CarPlay/Android Auto | standard | standard | standard | standard |
| Keyless open and start | not std | standard | standard | standard |
| Remote start | not std | standard | standard | standard |
| Roof rails | not std | standard | standard | standard |
| 1.3L engine | available | available | standard | standard |
| Off-road suspension + skid plate | not std | not std | not std | standard |
| Driver Confidence Package | available | available | available | available |
Full trim-by-trim pricing and package details are on the Trims and Pricing page.
Safety and Compliance
Driver-assistance content is not trim-gated here. The Chevy Safety Assist package — Forward Collision Alert, Automatic Emergency Braking with Front Pedestrian Braking, Lane Keep Assist with Lane Departure Warning, a Following Distance Indicator and IntelliBeam — arrives on the $23,300 LS exactly as it arrives on the $27,900 ACTIV, so the shopper working the bottom of the range gives up nothing that intervenes at speed.
Third-party testing lands in three places. The federal NHTSA program awards 5 stars for frontal crash protection and 4 for rollover resistance. IIHS rates it Good on the small overlap front and side tests, Acceptable on LATCH ease of use, Marginal on front pedestrian crash prevention, and Poor on front vehicle crash prevention. Headlights are the one rating that moves with the trim you pick: Acceptable on LS and LT, Poor on RS and ACTIV.
Warranty Coverage
| Coverage | Term |
|---|---|
| Bumper-to-bumper | 3 yr / 36,000 mi |
| Powertrain | 5 yr / 60,000 mi |
| Rust-through | 6 yr / 100,000 mi |
| Roadside assistance + courtesy transportation | 5 yr / 60,000 mi |
Full service intervals, covered maintenance and ownership costs are on the 2026 Trailblazer Maintenance and Service page.
What These 2026 Trailblazer Numbers Mean in Practice
| Spec | In Practice |
|---|---|
| 71.2 in. wide (excl. mirrors) | A standard 8-ft single-car garage bay clears it with roughly a foot to spare per side before mirrors, easier than most mid-size crossovers. |
| 174.1 in. long | A shade over 14.5 ft, so it fits a 16-ft driveway apron or a compact parking stall with room to spare, an easy fit around Diamondhead's condo and townhome parking. |
| 104.0 in. wheelbase, 39.0 in. rear legroom | Two adults sit behind two adults comfortably; three across the back is a short-trip proposition, normal for this class. |
| 13.2-gal tank at 31 mpg combined (1.3L FWD) | Roughly a 400-mile highway tank, so a round trip to Little Rock and back is one fill. |
| 1,000 lbs tow rating | Covers a small utility trailer; a boat or a pair of jet skis is outside this vehicle's brief. |
2026 Trailblazer Specifications FAQs
How much horsepower does the Trailblazer have?
137 horsepower from the standard 1.2L turbo, or 155 horsepower from the available 1.3L turbo, which is standard on RS and ACTIV.
How much cargo space does the Trailblazer have?
Fold the rear seats down and the cargo hold grows from 25.3 to 54.4 cubic feet, out of 123.5 cubic feet of total passenger volume measured across the whole cabin.
Does the ACTIV trim sit higher than the other trims?
ACTIV carries off-road-tuned suspension and a functional skid plate as documented standard equipment, aimed at gravel roads and rough lanes. See the Exterior Dimensions section above for the full dimensional table.
What is the Trailblazer's curb weight?
Approximately 3,029 pounds for a 1.2L front-wheel-drive model. Weight varies by engine and drivetrain; ask for the specific figure on the VIN you're considering.
What safety ratings does the Trailblazer have?
NHTSA rates it 5 stars frontal and 4 stars rollover. IIHS rates it Good on small overlap front and side tests, with headlight ratings that split by trim.
Is a sunroof available on the Trailblazer?
Yes, an available dual-pane panoramic power sunroof is offered on the lineup, confirmed directly by Chevrolet.
How big is the touchscreen?
11 inches, standard on every trim from LS on up, with wireless Apple CarPlay and Android Auto included.
How much can the Trailblazer tow?
Up to 1,000 pounds, properly equipped with the available trailering package, on front- or all-wheel drive.
