2026 Chevrolet Trax · Full Specifications
2026 Chevrolet Trax Specs & Dimensions | AR
Engine output, exterior and interior dimensions, cargo, wheels and tires, fuel economy, and what every number means day to day — verified for the 2026 Trax.
This page covers the complete technical specifications for the 2026 Chevrolet Trax — the numbers buyers from Hot Springs to Cedar Glades and Jones Mill actually shop on. For a plain-language overview of the model, see our 2026 Trax overview. For a trim-by-trim breakdown, see our Trax trims comparison. Every trim shares the same powertrain, so most specs below apply to the whole lineup.
Engine
Engine specifications
All five trims (LS, 1RS, LT, 2RS, ACTIV) run one engine and one drivetrain — there is no upgrade engine and no all-wheel-drive option.
| Engine | 1.2L turbocharged 3-cylinder (ECOTEC, direct injection) |
| Horsepower | 137 hp @ 5,000 rpm |
| Torque | 162 lb-ft @ 2,500 rpm |
| Transmission | 6-speed automatic |
| Drivetrain | Front-wheel drive (no AWD offered) |
| Fuel | Regular unleaded |
| Fuel tank | 13.2 gallons |
Exterior
Exterior dimensions
| Specification | Measurement |
|---|---|
| Overall length (inches) | 178.6 |
| Width, excluding mirrors (inches) | 71.8 |
| Height (inches) | 61.4 (LS, 1RS) / 61.7 (other trims) |
| Wheelbase (inches) | 106 |
| Ground clearance (inches) | 7.3 |
| Curb weight (pounds) | 2,983 to 3,040, by trim |
Interior
Interior dimensions and cargo
| Specification | Measurement |
|---|---|
| Seating capacity | 5, two rows |
| Front head / leg / shoulder room (inches) | 39.6 / 41.9 / 55.7 |
| Rear head / leg / shoulder room (inches) | 38.1 / 38.7 / 54.3 |
| Cargo behind rear seats (cubic feet) | 25.6 |
| Maximum cargo, seats folded (cubic feet) | 54.1 |
Rear legroom of 38.7 is unusually generous for a subcompact — closer to a midsize sedan than to most rivals. The rear seats fold to open up the 54.1-cubic-foot maximum.
Capability
Capacity and capability
The Trax is built as a city-and-highway crossover, not a hauler. It is not rated for towing — Chevrolet publishes no trailer-towing capacity for the Trax, so it should not be used to pull a trailer or camper. If you need to tow, step up to the Chevy Trailblazer, Equinox, or a Colorado pickup.
Where it delivers is cargo: 25.6 cubic feet behind the rear seats and 54.1 cubic feet with them folded — among the most usable space in the subcompact class, and the practical reason many buyers choose it.
Wheels & Tires
Wheels, tires, and brakes
| Trim | Wheels | Tires |
|---|---|---|
| LS | 17-inch steel | 225/60R17 |
| LT | 17-inch alloy | 225/60R17 |
| 1RS | 18-inch alloy | 225/55R18 |
| ACTIV | 18-inch alloy (black) | 225/55R18 |
| 2RS | 19-inch alloy | 245/45R19 |
All trims use four-wheel disc-style braking with the standard electronic stability and traction systems.
Efficiency
Fuel economy and range
Because there is a single front-wheel-drive configuration, the EPA estimates are the same across every trim: 28 mpg city, 32 mpg highway, and 30 mpg combined. Paired with the 13.2-gallon tank, that gives a long cruising range between fill-ups on regular unleaded.
| EPA estimate | All trims (FWD) |
|---|---|
| City (mpg) | 28 |
| Highway (mpg) | 32 |
| Combined (mpg) | 30 |
The window sticker on each vehicle is the figure that governs at purchase.
Safety
Safety and compliance
Standard on every trim (Chevy Safety Assist): automatic emergency braking, forward collision alert, lane-keep assist with lane-departure warning, automatic high beams, and a following-distance indicator, plus a rearview camera.
Available as you move up: blind-spot monitoring, rear cross-traffic alert, rear park assist, and adaptive cruise control — bundled in the Driver Confidence and LT Convenience packages, and not offered on the base LS.
NHTSA has not yet assigned the 2026 Trax a five-star overall rating, and per-test crash results are best confirmed at the source. Check nhtsa.gov and iihs.org for the current 2026 ratings before you buy.
In Practice
What these 2026 Trax numbers mean in practice
| What you are looking at | What it means around Hot Springs |
|---|---|
| About 15 feet long | Parks in a standard garage bay or compact spot — shorter than most sedans, easy to slot downtown. |
| Just under 6 feet wide (without mirrors) | Clears a standard single-car garage with room to open the doors; fold the mirrors for the tightest spaces. |
| Modest ground clearance | Handles speed bumps and the gravel drives common around Cedar Glades, but it is a paved-road crossover, not an off-roader. |
| A longer wheelbase than the footprint suggests | Settles the ride on a longer haul, like Highway 70 out toward Owensville, despite the compact size. |
| Near-midsize rear legroom | Adults fit in back for the daily Mountain Valley commute, not just kids — rare in this class. |
Specs FAQs
Specifications FAQs
How much horsepower does the 2026 Trax have?
Every 2026 Trax uses the same engine: a 1.2-liter turbocharged three-cylinder making 137 horsepower and 162 lb-ft of torque, paired with a six-speed automatic and front-wheel drive. Power is identical across all five trims, so the LS makes the same 137 horsepower as the ACTIV. Moving up the lineup changes wheels, screens, and equipment, not output.
How much cargo space does the 2026 Trax have?
Cargo space measures 25.6 cubic feet behind the rear seats and expands to 54.1 cubic feet with the rear seats folded down. That is generous for a subcompact SUV and one of the Trax's standout numbers, easily handling a big grocery run or weekend luggage. The seats fold flat to open up the longer load floor.
What are the 2026 Chevrolet Trax dimensions?
The 2026 Trax is a 178.6-inch-long, 71.8-inch-wide (without mirrors) subcompact that stands just over five feet tall — 61.4 to 61.7 depending on trim — on a 106-inch wheelbase with 7.3-inch ground clearance. Those are compact-SUV proportions: long enough inside for real rear-seat room, short enough outside to park easily. Curb weight runs from about 2,983 to 3,040 pounds depending on trim.
Will the 2026 Trax fit in a standard garage?
Yes. At about 15 feet long and just under 6 feet wide without the mirrors, the 2026 Trax fits comfortably in a standard single-car garage or a compact parking space, with room to open the doors. Drivers around Mountain Valley and Paron find it easy to maneuver and park, and the modest ground clearance handles gravel drives and speed bumps without scraping. Fold the mirrors in for the tightest spots.
Does the 2026 Trax come in all-wheel drive?
No. Like every Trax, the 2026 models are front-wheel drive only; there is no all-wheel-drive option on any trim. If you need all-wheel drive, the Chevy Trailblazer offers it in a similar size. For most drivers the Trax's front-wheel drive, paired with standard Chevy Safety Assist, is plenty for daily and all-season paved-road use.
